SNG, VSAT applications and BEACON

25 Gennaio 2016.

The field strength meter model HD RANGER UltraLite includes a brand new spectrum analyser function that makes it easy for technicians working in SNG vans and field VSAT applications to set up their satellite transmission-reception systems.

TV mobile unit and HD RANGER UltraLite field strength meter

Although this field strength meter has different no-error satellite identification functions, technicians working with these systems are often requested by the satellite operators to search for the "Beacon" signal as a mean of satellite identification.

This requires high resolution, high sensitivity and fast sweep times which are all readily available in the field strength meter model HD RANGER UltraLite product.

Spectrum showing BEACON signals
Spectrum showing BEACON signals
Outlined spectrum showing BEACON signals
Outlined spectrum
showing BEACON signals

10 MHz span with 100 kHz resolution bandwidth all that in 90 ms sweep time.
